SÖLL XENON HORIZONTAL LIFELINE

The Söll Xenon Horizontal lifeline system is the ideal solution for protecting workers at height.

The dual protection design of the Xenon system allows workers to be restrained from reaching a point where a potential fall hazard exists and also provides fall arrest protection in the event of a fall.

It's functional design was developed to allow increased freedom of movement at any angle and it is adapted to any style of work at height, be it in a straight line or installations around corners and bends.

Due to its versatility, simplicity and minimal maintenance, the Xenon Horizontal Lifeline is the perfect tool for engineers, contractors and architects to provide secure access on new and existing buildings.

Features include:

  • Compact stainless steel components
  • Improved worker safety
  • A versatile fixed horizontal lifeline certified for simultaneous use by up to 4 people
  • Minimum maintenance with fewer components
  • Innovative design
  • The system requires fewer parts
  • Easy to install on a variety of structures

SHUTTLE

The Söll Xenon Horizontal Lifeline Shuttle represents a revolutionary design with many innovative benefits.
  • Improved safety with a double locking mechanism.
  • User can connect and disconnect easily anywhere along the cable.
  • Ergonomically designed, the oversized handle allows the use of any type of certified connector.
  • Resistance to the environment - made of stainless steel with few moving parts, it is ideal for sandy, gritty or salty environments.
1005709 SHUTTLE SUITS BOTH 8mm AND 10mm SYSTEMS

INTERMEDIATE BRACKET AND CORNER UNITS

The intermediate bracket and corner units allow the shuttle to glide smoothly and easily over the connection.
  • Provides an easy passage of the shuttle through the hangers.
  • Designed to retain and transfer its load after a sustained fall.
  • The bracket can be replaced without cutting the cable.
1010609 UNIVERSAL INTERMEDIATE 8mm
1006062 CORNER UNIT 90 DEGREE 8mm
1006294 BENDING KIT 8mm

END ANCHORS AND SWAGES

  • Stainless steel end anchors and swages allow easy installation of the system without compromising cable strength and integrity.
  • End swages available with and without integrated tensioner.
  • Designed to accommodate a number of different swaging methods.
  • Swageless components also available.
1006178 END ANCHOR
1010891 ANCHORAGE RING - FEMALE
1006701 SWAGE 8mm
1010550 END TERMINATION WITH TENSIONER 8mm
1013720 SWAGELESS END TERMINATION 8mm

"FOUR-IN-ONE" SHOCK ABSORBER

  • A revolutionary "four-in-one" shock absorber, tensioning device, tension indicator and fall indicator.
  • The shock absorber reduces the load impact generated by a fall.
  • Protects the user as well as the supporting structure.
  • Integrated load indicator provides a visual indication, alerting the user to any load impact on the system.
  • Easier installation and maintenance - a single element allows you to both verify and adjust the tension easily.
1014930 INDUSTRY ENERGY ABSORBER 8mm
1014932 INDUSTRY ENERGY ABSORBER SWAGELESS 8mm
